Universal testing system Autograph AG-50kNXDplus, Shimadzu Load cell: 50kN Digital video extensometer TRViewX55S, Shimadzu Thermostatic chamber TCE-N300, Shimadzu Micro strain tester Micro Autograph MST-I typeHR, Shimadzu Load cell: 2kN and 50N Droptower impact system CEAST 9310, INSTRON Impact energy: 0.25-20.4J Impact velocity: 0.77-3.71m/s Servo-hydraulic testing machine Servopulser EHF-LV005k1-010, Shimadzu; Load capacity 5kN (at EN51-108, not working) Servo-hydraulic testing machine MTS810, MTS Load capacity 100kN (at EN70-103, not working) Sensor interface PCD-330B-F, Kyowa Strain sensing range: 20000με Max. sampling rate: 10kHz Data recording system EDX-10A, EDX-11A, EDX-12A, Kyowa Strain sensing range: 50000με Data logger GL220, GRAPHTEC 10 channels Sampling rate: 10ms-1h LCR meter IM3523, Hioki Combined loading compression (CLC) test fixture (ASTM D6641) for composite plates, Shimadzu Three- and four-point flexure test jig Shimadzu Double cantilever beam (DCB) test jig Shimadzu Indentation test jig (indenter diameter 20 mm; base diameter 75 mm) designed by Nakanishi (fy2020) Shear-cutting jig YAMASEI Spherically-seated compression plate Designed by Ono (fy2012) Micro-grip for Micro-Autograph, Shimadzu Pneumatic flat grips for Micro-Autograph, Shimadzu Grip plates with edge file C-shaped Grip plates for film specimens Compression plate Diameter: 100mm Compression plate Diameter: 50mm Optical microscope with camera BX51M with DP-21, OLYMPUS Total magnification ratio: 50-1000 200 million pixels Stereomicroscope SZX7, OLYMPUS Total magnification ratio: 8-56 Camera adapter NY-1S, Micronet Digital microscope VCR-800, HIROX 1x lens, 20x-160x zoom lens, Contact adapter High-speed microscope VW-9000, KEYENCE Able to record up to 230,000 fps LCD monitor, light source, HDD Black-and-white camera unit VW-300M with VHX-C mount, CV-L16 16mm lens, KEYENCE 1,000fps with 640X480 resolution Color camera unit VW-300C, KEYENCE with zoom lens VH-Z00W (x1-x50 magnification ratio) Long-focus zoom-lens VH-Z50L, KEYENCE (x50-x500 magnification ratio) PC microscope SKM-S30B-PC, Saitoh Kogaku 15x-180x, 130 million pixels Soft X-ray radiography system M-100, Softex Digital X-ray sensor NX-016H 136×102mm, 1209 million pixels Ultrasonic C-scan system TT-UTCS01, Tsukuba technology Contact-angle meter DMs-301, Kyowa Interface Science Hot-press machine SA-302, Tester Sangyo Max. 50kN; 250×250mm, Max. temperature 300℃ Vacuum pump DAP-6D, ULVAC Ultimate pressure 6.65 kPa Diamond saw TS-200PS, MARUTO Blade diameter 200mm Chest freezer SH-500XB, SANDEN -24 to -20℃ Inside size: 1200×583×753mm Vacuum chamber ADP300, Yamato Scientific G-101S, ULVAC 40-240℃, 300X300X300mm Temperature controller TJA-550P, AS ONE 0.0-200.0℃, φ4mm sheathed thermocouple (Pt100Ω) Halogen light source MegaLight 100, SCHOTT Ultraviolet LED light source ZUV-C20H, OMRON Parallel computation servers PRIMERGY TX300 S8, FUJITSU 2CPU Xeon E5-2643 v2 (3.5GHz/6core/25MB); 32GB Parallel computation server PRIMERGY TX2550, FUJITSU 2CPU Xeon Gold 6126 (2.6GHz/12core/19.3MB); 96GB 10kV AC/DC amplifier HVA4321, NF borrowed from Tohoku University Optical spectrum analyzer AQ6319, ANDO (Yokogawa) borrowed from Tohoku University ASE light source AQ4315A, ANDO (Yokogawa) Optical switch AQ8201-414 with frame AQ8203 ANDO (Yokogawa) borrowed from Tohoku University USB3 Camera BU series BU2409MG, USB 3.0 Type, (Toshiba Teli Corporation). Resolution: 5,320(H) x 4,600(V), Frame rate: 15fps. 50mm Lenz VS-LLD50 (VS Technology). Focal Length: 50 mm, Opti. Mag. Range: 0.05x- 0.3x, Sensor Size (max.): 4/3”. USB 3.0 cable, 3m, straight type, (Hirakawa Hewtech Corp.) UB3-ST-SA0-MBS-0300-00K. Calibrator DS-CAL-2.0 (DITECT Corporation). Array: 13×12, Grid Size: 2.0×2.0mm. Compact recording system EDX series: Control unit EDX-10B, Voltage Measuring Unit EDX-12A, and Strain measuring unit EDX-14A (KYOWA) Open-Hole Compression (OHC) test fixture (ASTM D6484-09) of CFRP Markforged Onyx Pro Composite 3D printer
